1B5-510 Goodyear High Durability Rear Air Suspension With Standard Specifications And Customization
Product Description:
Suspension Air Springs are air ride suspension systems designed to provide superior ride comfort, stability and handling. They are made of high-quality rubber and steel, making them highly durable and reliable for many years. They are also easy to install, requiring minimal effort and time. With a pressure range of 0.2-0.8 MPA, these air springs are suitable for a variety of applications. They are also backed by a one year warranty, guaranteeing their performance and reliability. Air Ride Suspension, Air Suspension Kits, and Air Bag Suspension Kits are all supported by these Air Springs, making them ideal for all types of vehicles.
Features:
- Product Name: Suspension Air Springs
- Warranty: One Year
- Packaging: Strong Carton Packaging
- Color: Black Rubber And White Zinc Iron Cover Plate
- Material: Rubber And Steel
- Goodyear P/N: 1B5-510,1B5 510,1B 5510
Goodyear B/N: 579-913-501,579913501,579 913 501
- Air Suspension Components
- Suspension Air Bags
- Air Bag Suspension Kits
Technical Parameters:
| Item | Details |
| Operating Temperature | 40℃ To +70℃ |
| Pressure Range | 0.2-0.8 MPA |
| Top Cover Plate Diameter | Ø85mm |
| Top Plate Hole/Stud Quantity | 2 pcs |
| Air Fitting | 1/4'' |
| Stud/Screw | M8X15mm |
| Top Cover Plate Stud to Stud Diameter | 44.5mm |
| Bottom Plate Stud to Stud Diameter | 44.5mm |
| Rubber Bellow Diameter(0.7Mpa) | Ø150mm |
| Max. Height | 120mm |
| Min. Height | 50mm |
| Natural Height | 90mm |
Technical Data: Goodyear 1B5-510
Top Cover Plate Diameter: 3.75
Tapped Hole on Top Retainers: 3/8-16
Air Fitting: 1/4NPTF
Center Diatance Between of Tapped Hole: 1.75
Bottom Cover Plate Diameter: 2.75
Tapped Hole on Pistons: 1/2-13
Max.Height: 4.8
Min.Height: 1.8
Support and Services:
Suspension Air Springs provide technical support and service to ensure our customers receive the highest level of quality and satisfaction. Our team of experts are available to answer any questions you may have regarding the installation and operation of our products. We offer troubleshooting assistance, product information, and technical documentation to help you get the most out of your suspension air springs. Our team of experienced technicians are also available to provide on-site installation and maintenance services.
Packing and Shipping:
Suspension Air Springs packaging and shipping includes:
- Packaging: Suspension Air Springs are packaged in corrugated cardboard boxes. The boxes are sealed with strong packing tape.
- Shipping: Suspension Air Springs are shipped via UPS, FedEx, or USPS.
